Aerosol Filling Machine
This aerosol filling machine is designed in one table with a set of liquid filling, valve fixing, crimping, and gas filling respectively. It handles 45-65mm; delivers a production output of 15-20 bottles per minute; and holds ±1% accuracy. Request a detailed specification sheet or a quote from Harsiddh Engineering.
Description
This aerosol filling machine is designed in one table with a set of liquid filling, valve fixing, crimping, and gas filling respectively. It can be applied to fill various regular aerosol products like pesticides, air freshener, body deodorant perfume, spray paint, furniture wax, car dust remover, tire repair spray, lubricants, anti-rust adhesive aerosol, etc. It is anti-explosion and safe for operating because of its complete pneumatic running system.
The acrylic safety protection shield can protect the operators from danger risk. Besides, the automatic pneumatic cans pushing mechanism relieves the operator much from hard work. The valve fixing mechanism can correct the valve so to ensure 100% good crimping. The mobile wheels' feet make it easy to move the machine.
Aerosol Filling Machine Technical Specification
| Production Capacity | 15-20 bottles per minute |
|---|---|
| Liquid Filling Volume | 20ml, 50ml, 100ml, 500ml, 750ml(optional) Gas Filling |
| Volume | 20ml, 50ml, 100ml, 300ml, 500ml(optional) Liquid Filling |
| Accuracy | ?±1% |
| Gas Filling Accuracy | ?±1% |
| Working Pressure | 0.65-1.0Mpa |
| Max. Air Consumption | 0.9m3/min |
| Applicable Aerosol Can Diameter | 45-65mm |
| Applicable Aerosol Can Height | 120-350mm |
| Applicable Valve Diameter | 25.4mm(1’’) |
| Dimension | 1200mm x 830mm x 1820mm |
| Weight | 250kg |
Video
Frequently Asked Questions
What container sizes does the Aerosol Filling Machine handle?
Aerosol Filling Machine's applicable Aerosol Can Diameter is 45-65mm.
How accurate is the Aerosol Filling Machine?
Aerosol Filling Machine's accuracy is ±1%.
What production output can I expect from the Aerosol Filling Machine?
Aerosol Filling Machine's production Capacity is 15-20 bottles per minute.
What are the dimensions of the Aerosol Filling Machine?
Aerosol Filling Machine's dimension is 1200mm x 830mm x 1820mm.
How much does the Aerosol Filling Machine weigh?
Aerosol Filling Machine's weight is 250kg.
What is the Liquid Filling Volume of the Aerosol Filling Machine?
Aerosol Filling Machine's liquid Filling Volume is 20ml, 50ml, 100ml, 500ml, 750ml(optional) Gas Filling.
