Auger Type Powder Filling Machine (Single / Double Head)
Harsiddh auger type powder filling machines provide exceptional powder filling operations to pharmaceuticals, food, biotech and agricultural firms. It is available in 2 models (HAPF-40 and HAPF-90); and is built to CE certified standards. Request a detailed specification sheet or a quote from Harsiddh Engineering.
Description
Harsiddh auger type powder filling machines provide exceptional powder filling operations to pharmaceuticals, food, biotech and agricultural firms. Both single and double auger types are robust and made in to international quality specifications. They are manufactured using corrosion free, high quality stainless steels that makes the equipment durable and enable aseptic and contamination free filling. Our auger type powder filler machines are CE certified and require little maintenance and able to provide high value and long service life.
Both single and double head auger type powder filling systems are designed to maximize production output and are able to fill varying containers ranging from 5 -200 grams. Auger Type Powder Filling Machine handle a wide range powders ranging from fine to granulated types. Parts are easily interchangeable and this reduces change over time while increasing flexibility and output. Auger Powder Fillers incorporate sensors to prevent powder filling when the container is not there. The single auger type has a throughput of 20 – 40 bottles per minute while the double head fills 30-80 bottles per minute.
The operation process of Auger Powder Filling Machine ensures great accuracy and wastage free filling. Dry sterile bottles are fed to the system using a conveyor belt. Auger Powder Filler then move to the feed turn table. Upon reaching the filling section, they are clamped and magnetic clutch rotates the auger so as to release a predetermined quantity.
Where the Auger Powder Filling Machine fits in your production line
In a typical dry syrup bottle line, the Auger Powder Filling Machine handles powder filling. Before it come bottle unscrambling and air jet and vacuum cleaning. After it come screw or ROPP capping and bottle labelling.
Other models in this range
- Rotary Dry Syrup Powder Filler HRDS-100 – rotary powder filling for syrup bottles
- Automatic Dry Syrup Powder Filling Line – 30–120 ml bottles, 30–200/min
Need help choosing? Send your requirement with your container size, fill volume and output, or contact our team in Ahmedabad.
The working Principle of Auger Type Powder Filling Machine
Auger Type Powder Filling Machine is a device to fill the right amount of product into a container. The name Auger derives from an auger screw which the machine uses for filling containers with liquid, semi-solid, powdery, and granular materials. Moving on to the principle of how an Auger Powder filling machine works, the whole set up is based on the fundamental of Positive Displacement screw operating under a constant head which displaces the product through a funnel into the container. The augur metering system or the auger powder filler has four parts:-
- Drive motor – This controls the speed and revolution of the auger.
- Hopper- This holds the product to be filled.
- Blender- This homogenizes the powder.
- Auger- This rotates vertically into the hopper to feed the product through the funnel.
- Auger Funnel (Tube) – This holds the final product and is an outlet through which augur doses.
Whereas different products require different speeds and precision, the augur type powder filling machine is tailored made.
Salient Features of the Auger Type Powder Filling Machine
- Compact design.
- Filling accuracy between +/- 1-2% in single dose.
- The outer body is covered with SS sheet.
- All the contacting parts of the auger powder filling machine are made up of SS316L.
- Considerably restrained change in changeable machine parts.
- Filling capacity from 5 grams to 200 grams with help of change parts.
- No container No Fill systems.
- A unit can fill multiplicity of fine and granulated powder and can be used for various types of containers.
- Servo motor for accurate and timely filling.
Auger Type Powder Filling Machine Technical Specification
| Model No. | HAPF-40 | HAPF-90 |
|---|---|---|
| Auger Head | Single Head Auger | Double Head Auger |
| Out Put per minute | 20 to 40 per minute | 40 to 80 per minute |
| Fill Size | 5 grams to 200 grams | 5 grams to 200 grams |
| Electrical Specification | For Main Machine – 1.5 H.P. / 415 Volts / 50 Hz For Conveyor – 0.25 H.P. / 415 Volts / 50 Hz |
For Main Machine – 1.5 H.P. / 415 Volts / 50 Hz For Conveyor – 0.25 H.P. / 415 Volts / 50 Hz |
| Machine Dimensions | 1200mm (L) X 800mm (W) X 1700mm (H) | 1800mm (L) X 800mm (W) X 1700mm (H) |
| Net Weight | 225 Kgs. | 410Kgs. |
| Gross Weight | 450 Kgs. | 700Kgs. |
| Input Specifications | Container Dia :: 25mm to 100mm Height :: 50mm to 250mm |
Container Dia :: 25mm to 100mm Height :: 50mm to 250mm |
Video
Frequently Asked Questions
What are the power requirements for the Auger Type Powder Filling Machine (Single / Double Head)?
Auger Type Powder Filling Machine (Single / Double Head)'s electrical Specification is For Main Machine – 1.5 H.P. / 415 Volts / 50 Hz For Conveyor – 0.25 H.P. / 415 Volts / 50 Hz.
What are the dimensions of the Auger Type Powder Filling Machine (Single / Double Head)?
Machine Dimensions varies by model — HAPF-40: 1200mm (L) X 800mm (W) X 1700mm (H); HAPF-90: 1800mm (L) X 800mm (W) X 1700mm (H).
How much does the Auger Type Powder Filling Machine (Single / Double Head) weigh?
Net Weight varies by model — HAPF-40: 225 Kgs; HAPF-90: 410Kgs.
What is the Out Put per minute of the Auger Type Powder Filling Machine (Single / Double Head)?
Out Put per minute varies by model — HAPF-40: 20 to 40 per minute; HAPF-90: 40 to 80 per minute.
What is the Fill Size of the Auger Type Powder Filling Machine (Single / Double Head)?
Auger Type Powder Filling Machine (Single / Double Head)'s fill Size is 5 grams to 200 grams.
What is the Input Specifications of the Auger Type Powder Filling Machine (Single / Double Head)?
Auger Type Powder Filling Machine (Single / Double Head)'s input Specifications is Container Dia :: 25mm to 100mm Height :: 50mm to 250mm.
Is the Auger Type Powder Filling Machine (Single / Double Head) built to pharmaceutical industry standards?
Yes — it is built to CE certified standards.
