Linear Bottle Washing Machine
Linear Bottle Washing Machine harsiddh Unimach Pvt Ltd manufactures top quality Linear Bottle Washing Machine for smooth and perfect operation. It is available in 2 models (HLBW-120 and HLBW-240); handles Dia. 32mm to 60mm & 38mm to 180mm in Height; delivers a production output of 7000 / Hour (Depend on size) and 14000 / Hour (Depend on size); and is built to CE certified standards. Request a detailed specification sheet or a quote from Harsiddh Engineering.
Description
Harsiddh Unimach Pvt Ltd manufactures top quality Linear Bottle Washing Machine for smooth and perfect operation. Their linear bottle washing equipment features six internal zones for washing available with 60 and 120 jets. The linear bottle washing machine is quite strong with contact parts manufactured from SS316-grade materials. Other than that, the main machine is constructed from SS304 materials. You can use this tool for washing bottles of approximately 10 to 200ml measurements. Additionally, the linear bottle washer machine is also attached with 2tanks and pumps, thus offering smooth operations. Our bottle machines have CE certifications.
One of the most beneficial features of the bottle washing machine is that its washing order and sequence entirely depend on customer needs. Additionally, the independent cleaning zones ensure zero contamination. The device exhibits a water-consumption capacity of 500 to 700 liters per hour. With this equipment, you will have the opportunity of distinguishing five different washing zones. Power consumption of the equipment is 5.0HP, which makes it energy efficient and low-power consuming. The bottle washing machine is also capable of producing 240 bottles in a minute and works on the linear cleaning mechanism.
With intermittent systems for washing bottles, this particular device provides a pristine clean washing experience. Automatic infeed and exit options offer complete freedom of operations. With air consumption of 25 to 30 CFM, the device happens to be the best choice for flat as well as round bottles.
Where the Linear Bottle Washing Machine fits in your production line
In a typical oral liquid bottle line, the Linear Bottle Washing Machine handles bottle washing or air jet cleaning. Before it come bottle unscrambling. After it come liquid filling, screw or ROPP capping, measuring cup placement, bottle labelling and visual inspection.
Other models in this range
- Semi-Automatic Rotary Bottle Washer – HRBW-100, 60–100 bottles/min
Need help choosing? Send your requirement with your container size, fill volume and output, or contact our team in Ahmedabad.
Salient Features of Linear Bottle Washing Machine
- 60 Jets for 6 washing internal zone.
- 20 Jets for External Wash (2 raw x 10).
- 25 Channel with 10 Pocket on each channel (250 Pocket).
- All contact parts made of SS316 material.
- Linear Bottle Washing Machine construction in SS304 material.
- Suitable for 10ml to 200ml Bottle Size*.
- Washing sequence can be made as per customers’ requirements.
- Attached with 2 Pumps and Tanks.
- Each washing zone with independent circuit to avoid contamination.
- Automatic Infeed and Exit of Bottles.
Linear Bottle Washing Machine Technical Specification
| Model No. | HLBW-120 | HLBW-240 |
| Output / Hour | 7000 / Hour (Depend on size) | 14000 / Hour (Depend on size) |
| Direction | Linear Tunnel Type | Linear Tunnel Type |
| Bottle Dia. | Dia. 32mm to 60mm & 38mm to 180mm in Height | Dia. 32mm to 60mm & 38mm to 180mm in Height |
| Bottle sizes | 10ml to 200ml | 10ml to 200ml |
| Contact Parts | Stainless Steel 316L | Stainless Steel 316L |
| Air Consumption | 12 to 15 CFM | 12 to 15 CFM |
| Washing Zone | 5 Zone Or can be set as per customer require sequences | 5 Zone Or can be set as per customer require sequences |
| Pumps & Water Tank | 2 Nos. Each having 6000 Litre / hour capacity & Centrifugal Pumps | 2 Nos. Each having 6000 Litre / hour capacity & Centrifugal Pumps |
| Electrical Input | 380 V, 3 Phase, 50 Hz, 4 wire | 380 V, 3 Phase, 50 Hz, 4 wire |
| Power Requirements | 4 H.P. For Main Machine | 5 H.P. For Main Machine |
| Utilities | Fresh Water, DM Water, WFI, Air – 30 CFM |
Fresh Water, DM Water, WFI, Air – 30 CFM |
| Working Height | 850 to 950mm adjustable | 850 to 950mm adjustable |
| Dimension | 2700mm (L) X 1400mm (W) X 1550mm (H) | 3180mm (L) X 2500mm (W) X 1650mm (H) |
Video
Frequently Asked Questions
What container sizes does the Linear Bottle Washing Machine handle?
Linear Bottle Washing Machine's bottle Dia. is Dia. 32mm to 60mm & 38mm to 180mm in Height.
What materials are the Linear Bottle Washing Machine's contact parts made from?
Linear Bottle Washing Machine's contact Parts is Stainless Steel 316L.
What production output can I expect from the Linear Bottle Washing Machine?
Output / Hour varies by model — HLBW-120: 7000 / Hour (Depend on size); HLBW-240: 14000 / Hour (Depend on size).
What are the power requirements for the Linear Bottle Washing Machine?
Linear Bottle Washing Machine's electrical Input is 380 V, 3 Phase, 50 Hz, 4 wire.
What are the dimensions of the Linear Bottle Washing Machine?
Dimension varies by model — HLBW-120: 2700mm (L) X 1400mm (W) X 1550mm (H); HLBW-240: 3180mm (L) X 2500mm (W) X 1650mm (H).
What is the Air Consumption of the Linear Bottle Washing Machine?
Linear Bottle Washing Machine's air Consumption is 12 to 15 CFM.
Is the Linear Bottle Washing Machine built to pharmaceutical industry standards?
Yes — it is built to CE certified standards.
