Semi Automatic Aluminum Tube Filling and Sealing Machine
Semi automatic tube filling machine is uses for the filling and sealing of aluminum tubes. It is available in 2 models (ATFM-S and ATFM-D); and delivers a production output of Up to 30 tubes per minute and Up to 50 tubes per minute. Request a detailed specification sheet or a quote from Harsiddh Engineering.
Description
Semi automatic tube filling machine is uses for the filling and sealing of aluminum tubes. This ergonomically designed machine is uses due to its efficiency and auto-drip free filling mechanism. As a comprehensive solution for filling and crimping operations, it is equipped with a temperature controller as well. This ensures smooth process and operation.
We are a leading manufacturer of aluminum tube filling machine in India offering this amazing machine with high-filling accuracy and adjustable filling volume. Owing to its speedy filling mechanism it is considered apt for filling, crimping & batch coding tubes with a variety of products.
Types of Tube Filling Machines We are Aluminium Tube Filling Machine manufacturer with below variants:
- Single Head Tube Filling Machine
- Double Head Tube Filling Machine
- 8 Stations Aluminium Tube Filling Machine
- 12 Stations Aluminium Tube Filling Machine
Where the Aluminium Tube Filling & Sealing Machine fits in your production line
In a typical tube filling line, the Aluminium Tube Filling & Sealing Machine handles tube filling and sealing. After it come inspection.
Other models in this range
- Semi-Automatic Aluminium Tube Filling Machine – 5–100 ml, up to 50 tubes/min
- Semi-Automatic Plastic Tube Filling Machine – 5–200 g, fill, seal and trim
- Tube Filling, Crimping & Batch Coding Machine – 8 stations for aluminium tubes
- Automatic Lami Tube Filling Machine – 10–200 ml, up to 60 tubes/min
- Cosmetic Bottle Filling Machine – 5–1000 ml, 50–120/min
- Lotion & Gel Filling Machine – 2 or 4 heads, 5–1000 ml
- Petroleum Jelly Filling Machine – 10–500 g, up to 50 jars/min
- Pain Balm Filling Machine – heated hopper, 10–500 g
- Automatic Tube Filling Machine HTF-40A – single head, lami and plastic tubes
- Double Head Tube Filling Machine HTF-70A – 60–80 tubes/min
- Automatic Aluminium Tube Filler HTF-40AL – 40–50 tubes/min
- Lip Balm Filling Machine – heated hopper, 10–500 g
- Spout Pouch Filling & Capping Machine – stand-up spout pouches
Need help choosing? Send your requirement with your container size, fill volume and output, or contact our team in Ahmedabad.
Working Principle of Tube Filling Machine
Our semi-automatic aluminum tube filler works functions on semi-automatic function and hence the operator manually feeds the tubes on to the feeder holding station. Once the tube reaches the filling station, the filling process gets done with specially designed filling syringe. There is a pneumatic cut-off system provided in the machine for drip free filling. After filling these tubes are forwarded to the crimping station. Crimping done in two phases – in phase one there is one side of the tube press then in second phase it has been crimped by two side folding. After crimping there is batch coding station where batch no and manufacturing date pressed batch stereo set. Duly filled, crimped and batch coded tubes are automatically ejected through automatic bottom pushed lever.
For more information related to our aluminum tube filling and sealing machine, feel free to get in touch with us. As a leading manufacturer of aluminum tube filler in India, we will be more than happy to answer all your queries.
Semi Automatic Aluminum Tube Filling and Sealing Machine Technical Specification
| Model | ATFM-S | ATFM-D |
|---|---|---|
| Production output | Up to 30 tubes per minute | Up to 50 tubes per minute |
| Number of filling heads | Single | Double |
| Number of filling stations | Eight | Eight |
| Fill Volume | 5ml to 100ml (with the help of interchangeable syringe & cups) | 5ml to 50ml (with the help of interchangeable syringe & cups) |
| Tube Size Diameter | 12mm to 25mm | 12mm to 25mm |
| Tube Size Length | 50mm to 200mm | 50mm to 200mm |
| Power Consumption | 1.5 H.P. | 3 H.P. |
| Electrical Characteristics | 440 Volts, 3 Phase, 50 hertz, four wire system | 440 Volts, 3 Phase, 50 hertz, four wire system |
| Overall Dimension | 1200mm (L) x 800mm (W) x 1800mm (H) approx. | 1350mm (L) x 950mm (W) x 1800mm (H) approx. |
| Net Weight | 350 Kgs. approx. | 450 Kgs. approx. |
| Gross Weight | 550 Kgs. approx. | 650 Kgs. approx. |
Video
Frequently Asked Questions
What production output can I expect from the Semi Automatic Aluminum Tube Filling and Sealing Machine?
Production output varies by model — ATFM-S: Up to 30 tubes per minute; ATFM-D: Up to 50 tubes per minute.
What are the power requirements for the Semi Automatic Aluminum Tube Filling and Sealing Machine?
Power Consumption varies by model — ATFM-S: 1.5 H.P; ATFM-D: 3 H.P.
What are the dimensions of the Semi Automatic Aluminum Tube Filling and Sealing Machine?
Overall Dimension varies by model — ATFM-S: 1200mm (L) x 800mm (W) x 1800mm (H) approx; ATFM-D: 1350mm (L) x 950mm (W) x 1800mm (H) approx.
How much does the Semi Automatic Aluminum Tube Filling and Sealing Machine weigh?
Net Weight varies by model — ATFM-S: 350 Kgs. approx; ATFM-D: 450 Kgs. approx.
What is the Fill Volume of the Semi Automatic Aluminum Tube Filling and Sealing Machine?
Fill Volume varies by model — ATFM-S: 5ml to 100ml (with the help of interchangeable syringe & cups); ATFM-D: 5ml to 50ml (with the help of interchangeable syringe & cups).
What is the Tube Size Diameter of the Semi Automatic Aluminum Tube Filling and Sealing Machine?
Semi Automatic Aluminum Tube Filling and Sealing Machine's tube Size Diameter is 12mm to 25mm.
